Carousel Installation Tips

The installation of amusement equipment can be said to be one of the important links in the operation of amusement equipment. Many people who have not been in contact with this industry do not know how to install it to save their worry and effort. Today, let's talk about the skills of the installation of amusement equipment carousel!

First, of course, is to install the center base and rails. This step is very important. Before installation, you must have a good understanding of the site before starting the installation. For users with more limited sites, you must find the center point, so that you can install in a limited space. The trick to finding the center point is very simple. The tools you need are a tape measure and a rope of several meters long. First, determine the overall diameter of the carousel of the amusement equipment to be installed, and then use the tape measure to measure the rope to mark a radius. Such as: a set of 12 carousel horses, the overall diameter is 5 meters, just measure a length of 2.5 meters of rope to mark. Then one person stands near the assumed center point of the field and fixes one end of the rope, and the other person picks up the other end of the rope and pulls a circle. When it is beyond the scope of the field, find another assumed center point. When it does not exceed the scope of the field, this The center point is right, after marking it, place the center base in this position. Then the next step is to fix the rail rod and install the rail, so far the base and rail part are installed.

Install the carousel. There is also a trick here. When installing the carousel, you don't need to install all of them first. First, install the rectangular disk with tires according to the label. After fixing with screws, you can push the disk to rotate to observe whether the tires are running on the track for irregularities, and then install the motor drive belt or chain. At this time, you can turn on the power and start it to test the operation. If there is a fault, you can quickly find the fault point and solve it. There is no need to disassemble the fan-shaped disk, saving time and improving installation efficiency.

Install the center column, top, cornices, lighting and decoration. It should be noted here that if it is a luxury carousel, the lower top part has endurance board or photo decoration, and it should be fixed on each lower roof frame before installation, because it will be very difficult to install decoration after all the frames are installed. The electrical equipment on the top part only has lights. You can connect all the lights in series and connect them to the conductive ring or transformer of the corresponding voltage. After installation, carefully check whether the connection of the line is correct to avoid short-circuit causes. Equipment failure.
